Makita DHS680Z 18V Brushless Circular Saw (Body Only)

Name: Makita DHS680Z 18V Brushless Circular Saw (Body Only)
SKU: MAKDHS680Z
Availability: InStock

£179.95 exc. Vat

The Makita DHS680 circular saw has a high efficiency brushless motor which provides higher power. It boasts an impressive no load speed of 5000rpm to the 165mm blade.

SKU: MAKDHS680Z Categories: Body Only Cordless Tools, Circular & Trim Saws - Cordless

Description

Makita DHS680Z 18V Cordless Lithium Ion Brushless Circular Saw – Body Only

The Makita DHS680 circular saw has a high efficiency brushless motor which provides higher power. It boasts an impressive no load speed of 5000rpm to the 165mm blade.

Features:

Bevel cuts up to 50°
Automatic Speed Control
Electric brake
Soft start
Electronic current limiter for overload protection
Tool Hanger
Twin LED job light
LED indicator panel with 3 LED’s has 3 funtions. 1 – monitor battery power remaining, 2 – indication of automatic speed control, 3 – indication of overload protection activation
Rear dust exhaust port
Large lock off lever
Compact and lightweight design is achieved by downsizing the motor and better placement of parts and by using durable but light magnesium die-cast for base, blade case and safety cover
Ergonomic soft grip handle
Blower function to clear wood dust from cutting line

Automatic speed control

Automatically changes the cutting speed according to load condition for an optimum operation:

On light duty: high-speed rotation mode
On heavy duty: high torque mode
1 solid green LED: high torque mode

Batteries, charger or kitbox are NOT included

Machine compatible with Makita BL1830, BL1840 and BL1850 batteries

Specification:

Blade Diameter: 165 mm
Max Cut @ 0°: 57 mm
Max Cut @ 45°: 41 mm
Max Cut @ 50°: 37 mm
Bore Diameter: 20 mm
Noise sound pressure: 83 dB(A)
Noise sound power: 94 dB(A)
Noise K factor: 3 dB(A)
Maximum Output: 680 w
No Load Speed: 5,000 rpm
Weight: 3.3kg
